What you need to know about this product
Number of units in the group: 1
Sale formula: Unit
Packaging type: syringe
Unit weight: 2 grams.
Recommended uses: Electronic devices.
Thermal paste components: metal oxides and silicon.
Operating temperature range: -30 to 300 degrees Celsius.
It includes a flat spoon.
It is a conductor of electricity.
a description
The silver cooling paste is made from modified silicone with added high thermal conductivity materials, providing superior heat dissipation performance. It fills all microscopic gaps between surfaces, eliminates trapped air, and offers extremely low thermal resistance.
It is chemically inert, non-corrosive and non-toxic, has excellent thermal stability and can operate at temperatures up to 250°C, and for short periods, at temperatures up to 300°C.
Technical specifications:
Conductivity: 1.6 W/mK
NLGI consistency score: 2
Penetration (mm/10): 265 ~ 295
Density: 2.4 ± 0.1 g/ml
Color: Gray
Package: 2g syringe
Main applications
Suitable for use where more efficient heat dissipation is needed, such as CPUs, high-performance processors, heat-generating sources, thermocouples, resistors, semiconductor assemblies, and other components.
Transportation and storage
It should be transported and stored in accordance with common practices for chemicals.
Handling and application method
Clean the surface with a damp cloth or isopropyl alcohol. Apply the heat-treated silver polish to the treated item or component. Using a spatula, spread the product evenly over the entire area to form a thin layer.
comments
The information and data provided are consistent with current knowledge gathered by qualified and reliable technicians and should be considered a guide. If used, the customer should test performance using the information we provide. These usage guidelines are not suggestions to infringe on patents or other legislation. Liability is limited to the product itself.
