New Stetsom 2448 processor with sequencing (launching) device
Description of the Stetsom STX2448 digital audio processor, 4 channels, 4 equalizers, stereo outputs, from 10 Hz to 22500 Hz:
For those who appreciate high-quality in-car audio, audio processors offer a significant improvement in sound quality while reducing distortion. These processors receive the signal from the vehicle and optimize the frequency response so that the sound doesn't suffer from sharp fluctuations and is delivered at its correct frequency.
The Stetsom STX2448 digital audio processor features two input channels and four output channels, along with a 15-band equalizer and 12 preset equalizer settings to closely match your voice. It covers the entire frequency range from low to high, with a response from 10 Hz to 22,500 Hz and high sensitivity, resulting in clearer and more enjoyable sound.
Technical specifications:
- Number of input channels: 2
- Number of output channels: 4
- Graphical input equalizer: 15 bands, ±12 dB gain, 12 equalizer presets
Parametric equivalent: Gain ± 12 dB (one input + 1 per output) Quality factor Q from 0.4 to 10.0
- Variable frequency divider: Butterworth 12/18/24/36/48 dB/8th; Linkwitz-riley 12/18/24/36/48 dB/8th
- Input/output orientation: A, B or A+B
- Delay: from 0 to 8 milliseconds (275 cm)
- Phase: 0 degrees or 180 degrees
- Selector: Threshold from -24 to 0 dB; Automatic attack/fire
- Exit gain: from -45 to +15 dB
- Main level: from 0 to 100%
- Save/Load Memory Locations: 5 memory locations
- Security: A 4-digit security password
- Sound generator: 10 Hz to 22 kHz, sound level from -60 to 0 dB
- Scanning: Initial and final frequency from 10 Hz to 22 kHz; level from -60 to 0 dB; speed control.
- Screen protection: Text that can be edited in 15 positions
Response time: 1.08 milliseconds
Input resistance: 10 kΩ
- Output resistance: 47 ohms
- Relação Sinal Ruído: >90dB
Harmonic distortion
- Total: Less than 0.01%
- Channel separation: >80 dB
- Frequency response: from 10 Hz to 22.5 kHz at -1 dB
- Maximum input voltage: 4.5V peak to peak (+6.3dB)
- Maximum output voltage: 4.5V peak to peak (+6.3dB)
- Food: 10V to 15V DC
- Current consumption: 350 mA at 12.6 V DC
Approximate dimensions (axis x length x width): 37 x 200 x 101 mm
Package contents:
- One digital audio processor
- One manual and warranty certificate
